UHE2A680MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE2A680MPD Datasheet
-
ECAD Model
- Share
In Stock: 6,945
Can ship immediately
Pricing:
- 1$0.57
- 10$0.40014
- 100$0.2638
- 500$0.1954
- 1,000$0.16609
- 2,500$0.15631
- 5,000$0.14655
Quote It
Technical Details
- Series:UHE
- Package:Bulk
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:280 mA @ 120 Hz
- Ripple Current @ High Frequency:400 mA @ 100 kHz
- Impedance:310 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
