RFS-25V470MG3#5
Elna America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet RFS-25V470MG3#5 Datasheet
-
ECAD Model
- Share
In Stock: 7,984
Can ship immediately
Pricing:
- 1$0.71
- 10$0.49909
- 100$0.32869
- 500$0.24349
- 1,000$0.20696
- 2,500$0.19479
- 5,000$0.18262
Quote It
Technical Details
- Series:RFS, SILMIC II
- Package:Bulk
- Part Status:Active
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:140 mA @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.453" (11.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
