B41888C5477M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41888C5477M000 Datasheet
-
ECAD Model
- Share
In Stock: 3,980
Can ship immediately
Pricing:
- 1$0.75
- 10$0.55038
- 100$0.37777
- 500$0.29903
- 1,000$0.25182
- 2,500$0.23608
- 5,000$0.22034
Quote It
Technical Details
- Series:B41888
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):64mOhm @ 10kHz
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:1.24 A @ 100 kHz
- Impedance:59 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
