EEU-FC1V271
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1V271 Datasheet
-
ECAD Model
- Share
In Stock: 1,846
Can ship immediately
Pricing:
- 1$0.79
- 10$0.55643
- 100$0.3666
- 500$0.27157
- 1,000$0.23084
- 2,500$0.21726
- 5,000$0.20368
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:682.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.05 A @ 100 kHz
- Impedance:68 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
