UHE1E102MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHE1E102MPD Datasheet
-
ECAD Model
- Share
In Stock: 6,750
Can ship immediately
Pricing:
- 1$0.92
- 10$0.6758
- 100$0.46364
- 500$0.36709
- 1,000$0.30912
- 2,500$0.2898
- 5,000$0.27048
Quote It
Technical Details
- Series:UHE
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:7000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.433 A @ 120 Hz
- Ripple Current @ High Frequency:1.91 A @ 100 kHz
- Impedance:31 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):1.240" (31.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
