16YXJ4700M16X25
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet 16YXJ4700M16X25 Datasheet
-
ECAD Model
- Share
In Stock: 6,001
Can ship immediately
Pricing:
- 1$1.2
- 10$0.90971
- 100$0.65074
- 500$0.50379
- 1,000$0.43383
- 2,500$0.40583
- 5,000$0.38485
Quote It
Technical Details
- Series:YXJ
- Package:Bulk
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.344 A @ 120 Hz
- Ripple Current @ High Frequency:2.93 A @ 100 kHz
- Impedance:21 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
