EEU-FC1V102S
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FC1V102S Datasheet
-
ECAD Model
- Share
In Stock: 3,414
Can ship immediately
Pricing:
- 1$1.25
- 10$0.98739
- 100$0.74059
- 500$0.55952
- 1,000$0.49369
- 2,500$0.46078
- 5,000$0.44761
Quote It
Technical Details
- Series:FC
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:1.654 A @ 120 Hz
- Ripple Current @ High Frequency:2.21 A @ 100 kHz
- Impedance:29 mOhms
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.787" (20.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
