B41888C7108M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41888C7108M000 Datasheet
-
ECAD Model
- Share
In Stock: 8,376
Can ship immediately
Pricing:
- 1$1.39
- 10$1.09821
- 100$0.82378
- 500$0.6224
- 1,000$0.54916
- 2,500$0.51255
- 5,000$0.49425
Quote It
Technical Details
- Series:B41888
- Package:Bulk
- Part Status:Active
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):30mOhm @ 10kHz
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:2.459 A @ 100 kHz
- Impedance:27 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
