35TRV2200M16X21.5
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 35V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet 35TRV2200M16X21.5 Datasheet
-
ECAD Model
- Share
In Stock: 5,543
Can ship immediately
Pricing:
- 1$2.49
- 75$1.68762
- 150$1.47663
- 375$1.2657
- 525$1.12505
- 750$1.05475
- 1,875$0.98443
- 3,750$0.95631
Quote It
Technical Details
- Series:TRV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.2 A @ 120 Hz
- Ripple Current @ High Frequency:2 A @ 100 kHz
- Impedance:41 mOhms
- Lead Spacing:-
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:0.669" L x 0.669" W (17.00mm x 17.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
