EKYB101ELL471MK40S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKYB101ELL471MK40S Datasheet
-
ECAD Model
- Share
In Stock: 1,725
Can ship immediately
Pricing:
- 1$2.25
- 10$1.80553
- 100$1.38838
- 500$1.08293
- 1,000$0.97186
- 2,500$0.91633
- 5,000$0.88856
Quote It
Technical Details
- Series:KYB
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:10000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.225 A @ 120 Hz
- Ripple Current @ High Frequency:2.45 A @ 100 kHz
- Impedance:24 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.634" (41.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
