400BXW120MEFR16X35
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 120UF 20% 400V T/H
- CategoryAluminum Electrolytic Capacitors
- Datasheet 400BXW120MEFR16X35 Datasheet
-
ECAD Model
- Share
In Stock: 467
Can ship immediately
Pricing:
- 1$2.92
- 10$2.35535
- 100$1.83699
- 500$1.36598
- 1,000$1.27178
- 2,500$1.22467
- 5,000$1.20112
Quote It
Technical Details
- Series:BXW
- Package:Bulk
- Part Status:Active
- Capacitance:120 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:12000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:810 mA @ 120 Hz
- Ripple Current @ High Frequency:1.823 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.295" (7.50mm)
- Size / Dimension:0.630" Dia (16.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
