UKW1H103MRD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKW1H103MRD Datasheet
-
ECAD Model
- Share
In Stock: 886
Can ship immediately
Pricing:
- 1$6
- 10$5.33151
- 100$4.2649
- 500$3.66513
- 1,000$3.62515
Quote It
Technical Details
- Series:UKW
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:4 A @ 120 Hz
- Ripple Current @ High Frequency:4.6 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.492" (12.50mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.969" (50.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
