USA1H010MDD1TP
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet USA1H010MDD1TP Datasheet
-
ECAD Model
- Share
In Stock: 6,194
Can ship immediately
Pricing:
- 1$0.29
- 2,000$0.05218
- 4,000$0.04744
- 10,000$0.04506
- 14,000$0.04269
- 50,000$0.03795
- 100,000$0.03202
Quote It
Technical Details
- Series:USA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:10 mA @ 120 Hz
- Ripple Current @ High Frequency:15 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.059" (1.50mm)
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.315" (8.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
