EEA-GA1H150H
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEA-GA1H150H Datasheet
-
ECAD Model
- Share
In Stock: 4,093
Can ship immediately
Pricing:
- 1$0.33
- 2,000$0.06765
- 4,000$0.06258
- 10,000$0.05919
- 14,000$0.05615
- 50,000$0.05074
- 100,000$0.04482
Quote It
Technical Details
- Series:GA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:15 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:55 mA @ 120 Hz
- Ripple Current @ High Frequency:85.25 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.276" (7.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
