UPS2F010MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1UF 20% 315V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPS2F010MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 4,866
Can ship immediately
Pricing:
- 1$0.39
- 1,000$0.07747
- 2,000$0.07378
- 5,000$0.06825
- 10,000$0.06456
- 25,000$0.05903
- 50,000$0.05534
- 100,000$0.04889
Quote It
Technical Details
- Series:UPS
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1 µF
- Tolerance:±20%
- Voltage - Rated:315 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:16 mA @ 120 Hz
- Ripple Current @ High Frequency:25.6 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
