UWT1H2R2MCL2GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2.2UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWT1H2R2MCL2GB Datasheet
-
ECAD Model
- Share
In Stock: 6,111
Can ship immediately
Pricing:
- 1$0.41
- 2,000$0.09272
- 4,000$0.08757
- 10,000$0.08242
- 14,000$0.07984
- 50,000$0.07212
- 100,000$0.06697
Quote It
Technical Details
- Series:UWT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:2.2 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:9 mA @ 120 Hz
- Ripple Current @ High Frequency:13.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.118" Dia (3.00mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.130" L x 0.130" W (3.30mm x 3.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
