EEE-HAJ101WAR
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 6.3V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEE-HAJ101WAR Datasheet
-
ECAD Model
- Share
In Stock: 35,100
Can ship immediately
Pricing:
- 1$0.42
- 1,000$0.10537
- 2,000$0.09982
- 5,000$0.09428
- 10,000$0.08872
- 25,000$0.08318
- 50,000$0.07764
- 100,000$0.07209
Quote It
Technical Details
- Series:HA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:47 mA @ 120 Hz
- Ripple Current @ High Frequency:79.9 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
