UPJ1J560MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 56UF 20% 63V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPJ1J560MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 3,080
Can ship immediately
Pricing:
- 1$0.49
- 1,000$0.10808
- 2,000$0.10239
- 5,000$0.0967
- 10,000$0.09101
- 25,000$0.08532
- 50,000$0.07964
- 100,000$0.07736
Quote It
Technical Details
- Series:UPJ
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:56 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:275 mA @ 120 Hz
- Ripple Current @ High Frequency:450 mA @ 10 kHz
- Impedance:310 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.630" (16.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
