UUQ1H100MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UUQ1H100MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 4,993
Can ship immediately
Pricing:
- 1$0.64
- 1,000$0.17884
- 2,000$0.16832
- 5,000$0.1578
- 10,000$0.14728
- 25,000$0.14202
- 50,000$0.13676
Quote It
Technical Details
- Series:UUQ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:30 mA @ 120 Hz
- Ripple Current @ High Frequency:45 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.213" (5.40mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
