UWP1E220MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 25V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWP1E220MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 2,227
Can ship immediately
Pricing:
- 1$0.74
- 1,000$0.17807
- 2,000$0.16759
- 5,000$0.15712
- 10,000$0.14665
- 25,000$0.14141
- 50,000$0.13617
Quote It
Technical Details
- Series:UWP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Bi-Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:50 mA @ 120 Hz
- Ripple Current @ High Frequency:75 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.327" L x 0.327" W (8.30mm x 8.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
