UWD1H100MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWD1H100MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 5,686
Can ship immediately
Pricing:
- 1$0.76
- 1,000$0.24487
- 2,000$0.22956
- 5,000$0.21426
- 10,000$0.20661
- 25,000$0.19895
- 50,000$0.19822
Quote It
Technical Details
- Series:UWD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:82.5 mA @ 120 Hz
- Ripple Current @ High Frequency:165 mA @ 100 kHz
- Impedance:880 mOhms
- Lead Spacing:-
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.240" (6.10mm)
- Surface Mount Land Size:0.260" L x 0.260" W (6.60mm x 6.60mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
