UPM1E330MDD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 33UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPM1E330MDD Datasheet
-
ECAD Model
- Share
In Stock: 4,605
Can ship immediately
Pricing:
- 1$0.33
- 10$0.22466
- 100$0.12731
- 500$0.08986
- 1,000$0.07863
- 2,500$0.07489
- 5,000$0.06928
Quote It
Technical Details
- Series:UPM
- Package:Bulk
- Part Status:Active
- Capacitance:33 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:88 mA @ 120 Hz
- Ripple Current @ High Frequency:155 mA @ 10 kHz
- Impedance:800 mOhms
- Lead Spacing:0.079" (2.00mm)
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
