UKW1A331MED
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 330UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UKW1A331MED Datasheet
-
ECAD Model
- Share
In Stock: 2,861
Can ship immediately
Pricing:
- 1$0.48
- 10$0.33015
- 100$0.19809
- 500$0.14857
- 1,000$0.12546
- 2,500$0.11885
- 5,000$0.11225
Quote It
Technical Details
- Series:UKW
- Package:Bulk
- Part Status:Active
- Capacitance:330 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:270 mA @ 120 Hz
- Ripple Current @ High Frequency:405 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.433" (11.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
