UHD1C471MPD6
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UHD1C471MPD6 Datasheet
-
ECAD Model
- Share
In Stock: 1,175
Can ship immediately
Pricing:
- 1$0.48
- 10$0.34186
- 100$0.22537
- 500$0.16694
- 1,000$0.14191
- 2,500$0.13356
- 5,000$0.12521
Quote It
Technical Details
- Series:UHD
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:4000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:772.5 mA @ 120 Hz
- Ripple Current @ High Frequency:1.03 A @ 100 kHz
- Impedance:53 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
