EEU-FS2A270
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 27UF 20% 100V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet EEU-FS2A270 Datasheet
-
ECAD Model
- Share
In Stock: 3,867
Can ship immediately
Pricing:
- 1$0.58
- 10$0.40714
- 100$0.26771
- 500$0.19834
- 1,000$0.16858
- 2,500$0.15867
- 5,000$0.14875
Quote It
Technical Details
- Series:FS
- Package:Bulk
- Part Status:Active
- Capacitance:27 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:6000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:269.5 mA @ 120 Hz
- Ripple Current @ High Frequency:490 mA @ 100 kHz
- Impedance:160 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.512" (13.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
