UBT1H100MPD8
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 50V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
- Datasheet UBT1H100MPD8 Datasheet
-
ECAD Model
- Share
In Stock: 1,131
Can ship immediately
Pricing:
- 1$0.58
- 10$0.40941
- 100$0.26931
- 500$0.19948
- 1,000$0.16956
- 2,500$0.15958
- 5,000$0.14961
Quote It
Technical Details
- Series:UBT
- Package:Bulk
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:90 mA @ 120 Hz
- Ripple Current @ High Frequency:180 mA @ 100 kHz
- Impedance:750 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.531" (13.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
