B41821A4108M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1000UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41821A4108M000 Datasheet
-
ECAD Model
- Share
In Stock: 9,696
Can ship immediately
Pricing:
- 1$0.6
- 10$0.42808
- 100$0.282
- 500$0.20884
- 1,000$0.17752
- 2,500$0.16708
- 5,000$0.15663
Quote It
Technical Details
- Series:B41821
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:1000 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):330mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:790 mA @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.669" (17.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
