UVK1C222MPD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 16V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVK1C222MPD Datasheet
-
ECAD Model
- Share
In Stock: 1,592
Can ship immediately
Pricing:
- 1$0.8
- 10$0.58857
- 100$0.40343
- 500$0.31943
- 1,000$0.26899
- 2,500$0.25218
- 5,000$0.23536
Quote It
Technical Details
- Series:UVK
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1 A @ 120 Hz
- Ripple Current @ High Frequency:1.15 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
