EEU-FP1E152B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 25V THRUHOLE
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 3,041
Can ship immediately
Pricing:
- 1$1.85
- 500$1.85
- 1,000$1.63233
- 2,500$1.52351
- 5,000$1.46911
- 12,500$1.38749
Quote It
Technical Details
- Series:FP
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):38mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.1125 A @ 120 Hz
- Ripple Current @ High Frequency:3.25 A @ 100 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):0.866" (22.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
