EKZE101ELL271MK30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 270UF 20% 100V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet EKZE101ELL271MK30S Datasheet
-
ECAD Model
- Share
In Stock: 1,133
Can ship immediately
Pricing:
- 1$1.96
- 10$1.5784
- 100$1.21402
- 500$0.94683
- 1,000$0.84971
- 2,500$0.80115
- 5,000$0.77687
Quote It
Technical Details
- Series:KZE
- Package:Bulk
- Part Status:Active
- Capacitance:270 µF
- Tolerance:±20%
- Voltage - Rated:100 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:750 mA @ 120 Hz
- Ripple Current @ High Frequency:1.5 A @ 100 kHz
- Impedance:42 mOhms
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.492" Dia (12.50mm)
- Height - Seated (Max):1.181" (30.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
