EMVH500GDA471MMH0S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 50V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet EMVH500GDA471MMH0S Datasheet
-
ECAD Model
- Share
In Stock: 349
Can ship immediately
Pricing:
- 1$3.56
- 150$2.52436
- 300$2.07127
- 750$1.78
- 1,050$1.74764
- 3,750$1.68291
Quote It
Technical Details
- Series:Alchip™- MVH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):150mOhm @ 100kHz
- Lifetime @ Temp.:5000 Hrs @ 125°C
- Operating Temperature:-40°C ~ 125°C
- Polarization:Polar
- Ratings:-
- Applications:Automotive
- Ripple Current @ Low Frequency:460 mA @ 120 Hz
- Ripple Current @ High Frequency:920 mA @ 100 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.709" Dia (18.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:0.748" L x 0.748" W (19.00mm x 19.00mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
