16MXG6800MEFCSN20X25
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 6800UF 20% 16V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 16MXG6800MEFCSN20X25 Datasheet
-
ECAD Model
- Share
In Stock: 305
Can ship immediately
Pricing:
- 1$3.23
- 10$2.60435
- 100$2.03159
- 500$1.51067
- 1,000$1.40648
- 2,500$1.3544
- 5,000$1.32834
Quote It
Technical Details
- Series:MXG
- Package:Bulk
- Part Status:Active
- Capacitance:6800 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.8 A @ 120 Hz
- Ripple Current @ High Frequency:2.07 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.787" Dia (20.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
