B43501A5476M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 47UF 20% 450V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43501A5476M000 Datasheet
-
ECAD Model
- Share
In Stock: 201
Can ship immediately
Pricing:
- 1$3.45
- 10$2.77992
- 100$2.16836
- 500$1.61236
- 1,000$1.50116
- 2,500$1.44556
- 5,000$1.41776
Quote It
Technical Details
- Series:B43501
- Package:Bulk
- Part Status:Not For New Designs
- Capacitance:47 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):2.82Ohm @ 100Hz
- Lifetime @ Temp.:10000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:510 mA @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:3.39 Ohms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.063" (27.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
