80MXG3300MEFCSN22X50
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 3300UF 20% 80V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 80MXG3300MEFCSN22X50 Datasheet
-
ECAD Model
- Share
In Stock: 292
Can ship immediately
Pricing:
- 1$5.52
- 10$4.91103
- 100$3.92845
- 500$3.37605
- 1,000$3.13051
- 2,500$3.06914
Quote It
Technical Details
- Series:MXG
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:80 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.64 A @ 120 Hz
- Ripple Current @ High Frequency:3.036 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
