420MXK390MEFCSN25X45
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 390UF 20% 420V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 420MXK390MEFCSN25X45 Datasheet
-
ECAD Model
- Share
In Stock: 524
Can ship immediately
Pricing:
- 1$8.13
- 10$7.22667
- 200$5.78133
- 600$4.96833
- 1,000$4.91413
Quote It
Technical Details
- Series:MXK
- Package:Tray
- Part Status:Active
- Capacitance:390 µF
- Tolerance:±20%
- Voltage - Rated:420 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.96 A @ 120 Hz
- Ripple Current @ High Frequency:2.744 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.850" (47.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
