ALA7DA561DE450
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALU SNAP IN 560UF 450V
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 325
Can ship immediately
Pricing:
- 1$8.95
- 10$7.95701
- 100$6.36561
- 500$5.47044
- 1,000$5.0726
Quote It
Technical Details
- Series:ALA7D
- Package:Bulk
- Part Status:Active
- Capacitance:560 µF
- Tolerance:±20%
- Voltage - Rated:450 V
- ESR (Equivalent Series Resistance):275.2mOhm @ 100Hz
- Lifetime @ Temp.:15000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:2.19 A @ 100 Hz
- Ripple Current @ High Frequency:5.01 A @ 10 kHz
- Impedance:207.2 mOhms
- Lead Spacing:-
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):1.850" (47.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
