MAL205657103E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 40V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet MAL205657103E3 Datasheet
-
ECAD Model
- Share
In Stock: 686
Can ship immediately
Pricing:
- 1$10.21
- 10$9.07141
- 100$7.25713
- 500$6.23659
- 1,000$6.16856
Quote It
Technical Details
- Series:056 PSM-SI
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:40 V
- ESR (Equivalent Series Resistance):38mOhm @ 100Hz
- Lifetime @ Temp.:12000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:4.2 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:28 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.181" Dia (30.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
