UWF1A220MCL1GB
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UWF1A220MCL1GB Datasheet
-
ECAD Model
- Share
In Stock: 2,977
Can ship immediately
Pricing:
- 1$0.4
- 1,000$0.08652
- 2,000$0.08197
- 5,000$0.07742
- 10,000$0.07286
- 25,000$0.06831
- 50,000$0.06375
- 100,000$0.0592
Quote It
Technical Details
- Series:UWF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:-
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:40 mA @ 120 Hz
- Ripple Current @ High Frequency:80 mA @ 100 kHz
- Impedance:2.6 Ohms
- Lead Spacing:-
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.217" (5.50mm)
- Surface Mount Land Size:0.209" L x 0.209" W (5.30mm x 5.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
