UCL1A220MCL1GS
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 22UF 20% 10V SMD
- CategoryAluminum Electrolytic Capacitors
- Datasheet UCL1A220MCL1GS Datasheet
-
ECAD Model
- Share
In Stock: 2,676
Can ship immediately
Pricing:
- 1$0.54
- 2,000$0.12206
- 4,000$0.11528
- 10,000$0.1085
- 14,000$0.10511
- 50,000$0.09494
- 100,000$0.08815
Quote It
Technical Details
- Series:UCL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:22 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:80 mA @ 120 Hz
- Ripple Current @ High Frequency:160 mA @ 100 kHz
- Impedance:850 mOhms
- Lead Spacing:-
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.228" (5.80mm)
- Surface Mount Land Size:0.169" L x 0.169" W (4.30mm x 4.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
