UVK1H221MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 220UF 20% 50V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVK1H221MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 2,102
Can ship immediately
Pricing:
- 1$0.53
- 500$0.16482
- 1,000$0.1401
- 2,500$0.13186
- 5,000$0.12361
- 12,500$0.11332
- 25,000$0.11208
Quote It
Technical Details
- Series:UVK
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:220 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:430 mA @ 120 Hz
- Ripple Current @ High Frequency:645 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.197" (5.00mm)
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.551" (14.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
