UPA1A821MPD1TD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 820UF 20% 10V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UPA1A821MPD1TD Datasheet
-
ECAD Model
- Share
In Stock: 4,533
Can ship immediately
Pricing:
- 1$0.78
- 1,000$0.22913
- 2,000$0.21565
- 5,000$0.20218
- 10,000$0.1887
- 25,000$0.18196
- 50,000$0.17522
Quote It
Technical Details
- Series:UPA
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:820 µF
- Tolerance:±20%
- Voltage - Rated:10 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:645 mA @ 120 Hz
- Ripple Current @ High Frequency:860 mA @ 100 kHz
- Impedance:62 mOhms
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.650" (16.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
