EDH158M6R3A9PAA
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM SMD 105C 1500UF 6VDC
- CategoryAluminum Electrolytic Capacitors
- Datasheet EDH158M6R3A9PAA Datasheet
-
ECAD Model
- Share
In Stock: 3,614
Can ship immediately
Pricing:
- 1$0.78
- 500$0.244
- 1,000$0.2074
- 2,500$0.1952
- 5,000$0.183
- 12,500$0.16775
- 25,000$0.16592
Quote It
Technical Details
- Series:EDH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:6.3 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:460 mA @ 120 Hz
- Ripple Current @ High Frequency:575 mA @ 10 kHz
- Impedance:-
- Lead Spacing:-
- Size / Dimension:0.394" Dia (10.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:0.406" L x 0.406" W (10.30mm x 10.30mm)
- Mounting Type:Surface Mount
- Package / Case:Radial, Can - SMD
