UVK1V680MED
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 68UF 20% 35V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UVK1V680MED Datasheet
-
ECAD Model
- Share
In Stock: 3,518
Can ship immediately
Pricing:
- 1$0.33
- 10$0.22417
- 100$0.12687
- 500$0.08957
- 1,000$0.07839
- 2,500$0.07465
- 5,000$0.06905
Quote It
Technical Details
- Series:UVK
- Package:Bulk
- Part Status:Active
- Capacitance:68 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:160 mA @ 120 Hz
- Ripple Current @ High Frequency:320 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
