400MXG100MEFCSN20X30
Rubycon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 100UF 20% 400V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 400MXG100MEFCSN20X30 Datasheet
-
ECAD Model
- Share
In Stock: 355
Can ship immediately
Pricing:
- 1$2.76
- 10$2.22333
- 100$1.73452
- 500$1.28974
- 1,000$1.2008
- 2,500$1.15633
- 5,000$1.15209
Quote It
Technical Details
- Series:MXG
- Package:Bulk
- Part Status:Active
- Capacitance:100 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-25°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:870 mA @ 120 Hz
- Ripple Current @ High Frequency:1.218 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.787" Dia (20.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
