478LBA035M2BD
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 4700UF 20% 35V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 478LBA035M2BD Datasheet
-
ECAD Model
- Share
In Stock: 1,234
Can ship immediately
Pricing:
- 1$2.91
- 10$2.34746
- 100$1.83102
- 500$1.36152
- 1,000$1.27702
Quote It
Technical Details
- Series:LBA
- Package:Bulk
- Part Status:Active
- Capacitance:4700 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):141.09mOhm @ 120Hz
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.4 A @ 120 Hz
- Ripple Current @ High Frequency:3 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.260" (32.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
