LGU1E123MELA
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 12000UF 20% 25V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LGU1E123MELA Datasheet
-
ECAD Model
- Share
In Stock: 419
Can ship immediately
Pricing:
- 1$3.5
- 10$2.82198
- 100$2.20086
- 500$1.63651
- 1,000$1.53493
Quote It
Technical Details
- Series:LGU
- Package:Bulk
- Part Status:Active
- Capacitance:12000 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.81 A @ 120 Hz
- Ripple Current @ High Frequency:3.2315 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.654" (42.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
