LKG1H222MESCBK
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 2200UF 20% 50V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet LKG1H222MESCBK Datasheet
-
ECAD Model
- Share
In Stock: 308
Can ship immediately
Pricing:
- 1$4.11
- 10$3.69617
- 100$2.79253
- 500$2.29975
- 1,000$2.23404
Quote It
Technical Details
- Series:LKG
- Package:Bulk
- Part Status:Active
- Capacitance:2200 µF
- Tolerance:±20%
- Voltage - Rated:50 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:1000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:Audio
- Ripple Current @ Low Frequency:2.25 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):0.787" (20.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
