381LX153M016J032
Cornell Dubilier Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 15000UF 20% 16V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet 381LX153M016J032 Datasheet
-
ECAD Model
- Share
In Stock: 992
Can ship immediately
Pricing:
- 1$4.28
- 10$3.84822
- 100$2.90719
- 500$2.39415
- 1,000$2.22314
- 2,500$2.18039
Quote It
Technical Details
- Series:381LX
- Package:Bulk
- Part Status:Active
- Capacitance:15000 µF
- Tolerance:±20%
- Voltage - Rated:16 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:3.2 A @ 120 Hz
- Ripple Current @ High Frequency:3.7 A @ 20 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.984" Dia (25.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
