B43508A2477M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 470UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B43508A2477M000 Datasheet
-
ECAD Model
- Share
In Stock: 671
Can ship immediately
Pricing:
- 1$4.35
- 10$3.9192
- 100$2.96126
- 500$2.43865
- 1,000$2.26446
- 2,500$2.22092
Quote It
Technical Details
- Series:B43508
- Package:Bulk
- Part Status:Active
- Capacitance:470 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):250mOhm @ 100Hz
- Lifetime @ Temp.:3000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:1.36 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:340 mOhms
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):1.457" (37.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
