ESMQ201VSN681MQ30S
United Chemi-Con
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 680UF 20% 200V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet ESMQ201VSN681MQ30S Datasheet
-
ECAD Model
- Share
In Stock: 268
Can ship immediately
Pricing:
- 1$4.49
- 10$3.61928
- 100$2.82304
- 500$2.09918
- 1,000$1.95441
- 2,500$1.88202
- 5,000$1.84583
Quote It
Technical Details
- Series:SMQ
- Package:Bulk
- Part Status:Active
- Capacitance:680 µF
- Tolerance:±20%
- Voltage - Rated:200 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:2.68 A @ 120 Hz
- Ripple Current @ High Frequency:4.02 A @ 50 kHz
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:1.000" Dia (25.40mm)
- Height - Seated (Max):1.181" (30.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
